Elumen8 Evora CMY350 Profile - 350W CMY Moving Head with Framing Shutters
The Elumen8 Evora CMY350 Profile is a feature-packed and immensely bright 350W moving head with crystal clear optics, designed to meet the rigorous demands of professional lighting. This impressive fixture offers a 4-blade, rotatable framing system, a broad 3°- 53° motorized zoom, and precise control over focus and iris, allowing for intricate beam shaping. Further enhancing its array of features are a rotating gobo wheel, dual prisms, and two variable frost filters. With seamless CMY color mixing, a variable CTO flag, and a color wheel, a limitless number of shades can be achieved. Suited for rental, stage, and touring productions, this fixture is flicker-free and features a comprehensive suite of control options, including onboard wireless DMX, making it a powerful and versatile lighting tool.
Key Features
Powerful 350W White LED Source: Equipped with a high-output 350W white LED (6,900K), delivering immense brightness and exceptional clarity for all your lighting needs.
Precise 4-Blade Rotatable Framing System: Features an advanced 4-blade, rotatable framing system (+/-45° rotation), allowing for precise control over the beam's shape and size, and creating stunning profile effects.
Motorized Zoom, Focus, and Iris: A comprehensive set of motorized controls provides a broad 3°- 53° zoom range, precise focus adjustment, and a fully controllable iris for sharp, well-defined beams or wide washes.
Versatile Color Mixing & Effects:
CMY Color Mixing: Achieve an endless spectrum of colors with CMY (Cyan, Magenta, Yellow) color mixing (0-100%).
Variable CTO Flag: A dedicated variable CTO flag (0-100%) allows for continuous color temperature adjustment, from cool to warm whites.
Color Wheel: Includes a separate color wheel with 7 colors plus a High CRI filter (CRI: 84) and open, for quick color changes and enhanced color rendering.
Dual Rotating Prisms & Frost Filters:
Prisms: Features a 6-facet circular rotating indexable prism and a 6-facet linear rotating indexable prism, for creating mesmerizing multi-beam effects.
Frost Filters: Includes two variable frost filters for softening the beam and transitioning from a hard-edge profile to a wash effect.
Dynamic Gobo & Animation Wheels:
Gobo Wheel: Offers a gobo wheel with 7 rotating, indexable, replaceable gobos plus open, providing a versatile range of patterns and textures.
Animation Wheel: Includes a dedicated animation wheel for creating dynamic, flowing visual effects.
Comprehensive Control Protocols: Supports DMX, RDM, Kling-Net, Art-NET, and sACN protocols, ensuring seamless integration into any modern lighting network.
Onboard Wireless DMX: Features on-board wireless DMX via W-DMX Sweden transceiver. This allows the fixture to not only receive a wireless DMX signal but also relay it via the XLR output to other DMX fixtures, simplifying your cabling. An integral Art-Net node facilitates Art-Net to DMX conversion for downstream control.
High-Performance Build: The LED is flicker-free with an adjustable refresh rate (14 selectable presets between 900Hz-25kHz), making it perfect for broadcast and film. It is fitted with temperature-controlled fans for efficient and quiet cooling, and a Pan/tilt transit lock and auto correction for reliable operation.
Warranty: Comes with a 2-year warranty.
Technical Specifications
LED Source: 1 x 350W white LED (6,900K)
Adjustable Beam Angle: 3°- 53° (motorized zoom)
Framing Shutters: 4 rotating, +/-45° with shape rotation
Lumens – Source: 20,500 lm
Lumens – Output: 13,000 lm
Lux @ 10m: 3° - 21,200 Lux, 53° - 310 Lux
CRI: 71 (Color wheel includes a High CRI filter with a rating of 84)
Prisms: 6-facet circular, 6-facet linear
Gobo Wheel: 7 rotating, indexable, replaceable gobos + open
Color Mixing: CMY (0-100%), variable CTO flag (0-100%), color wheel (7 colors + High CRI filter)
Control Protocols: DMX, RDM, Kling-Net, Art-net, sACN, Wireless DMX (W-DMX Sweden)
DMX Channels: 34/41 or 55 selectable
Pan: 540° or 630° selectable
Tilt: 270° (16-Bit positioning with auto correction)
Dimming: 0 – 100% (5 dimming modes)
Power Consumption: 608W
Power Supply: 100~240V 50/60Hz
Fuse: T8A 250V
Noise Level: ≤40dBA @ 1m (low), ≤50dBA (auto), ≤55dBA (high)
Dimensions (H x D x W): 594 x 362 x 232mm
Weight: 22kg
What's in the box
Elumen8 Evora CMY350 Profile Moving Head
Quick release omega clamps
PowerTwist TR1 cable
User manual
USB port (for firmware updates)
Supplied with an additional 10 rotating gobos
Suitable For
Rental companies and touring productions
Large stages and concert venues
Theatrical and broadcast applications
Film and TV studios
Event production demanding precise beam shaping and high output
Fixed installations requiring advanced features
Read more less
