Electro-Voice ETX Quad ETX35P ETX18SP Power Pack
The Electro-Voice ETX Quad ETX35P & ETX18SP Power Pack is a premium, all-in-one audio solution designed for professional live sound applications, delivering a massive 11,600W total power output. This comprehensive PA package includes two ETX-35P 2000W three-way active speakers, featuring 15" woofers, 6.5" midrange drivers, and 1.25" compression drivers for exceptional clarity and coverage, and four ETX-18SP 1800W active subwoofers, each with an 18" woofer for thunderous bass down to 28 Hz. The bundle also comes with six 6m XLR-to-XLR signal cables for seamless connectivity. Built with tour-grade birch plywood enclosures and advanced FIR-Drive DSP, this system offers unparalleled sound quality, versatility, and durability, making it ideal for large venues, festivals, and demanding performances.
Key features:
Product Name: Electro-Voice ETX Quad ETX35P & ETX18SP Power Pack
Package Components:
2 x ETX-35P 15" Three-Way Powered Loudspeakers
4 x ETX-18SP 18" Powered Subwoofers
6 x XLR-to-XLR 6m signal cables
Total Power Output: 11,600W (2 x 2000W from ETX-35P + 4 x 1800W from ETX-18SP)
ETX-35P Specs:
Amplifier: 2000W Class-D
Maximum SPL: 136 dB
Frequency Response (-10 dB): 38 Hz - 20 kHz
Coverage: 60° H x 40° V
Transducers: 15" SMX2151 woofer, 6.5" MF8 midrange, 1.25" DH3-B titanium compression driver
Inputs: 2x XLR/TRS combo, 1x XLR link output
Enclosure: 18-mm, 13-ply birch plywood with EVCoat
Dimensions: 1023 mm x 469 mm x 426 mm (40.3" x 18.5" x 16.8")
Weight: 38.2 kg (84.2 lbs)
ETX-18SP Specs:
Amplifier: 1800W Class-D
Maximum SPL: 135 dB
Frequency Response (-10 dB): 28 Hz - 180 Hz
Transducer: 18" DVX3180A woofer
Inputs: 2x XLR/TRS combo, 2x XLR link outputs
Enclosure: 18-mm, 13-ply birch plywood with EVCoat
Dimensions: 576 mm x 601 mm x 825 mm (22.7" x 23.7" x 32.5")
Weight: 51.8 kg (114.2 lbs)
Power Requirements: 100-240V, 50-60 Hz
Key features:
FIR-Drive DSP: Advanced digital signal processing with presets, EQ, and limiters for precise audio tuning
SST Waveguide: Signal Synchronised Transducers for consistent coverage and minimal distortion (ETX-35P)
Cardioid Control: Directional bass steering with multiple ETX-18SP units for reduced stage noise
Tour-Grade Build: Durable birch plywood enclosures with EVCoat finish and steel grilles
Thermal Management: Intelligent system ensures reliability under heavy use
Connectivity: Comprehensive XLR inputs/outputs with included 6m cables for immediate setup
Highlights:
Massive Power: 11,600W total output for large venues and high-energy events
Full-Range Sound: Three-way ETX-35P design plus quad 18" subs deliver exceptional clarity and deep bass
Ready-to-Use Package: Includes all necessary cables for a complete PA system
Professional Versatility: Ideal for festivals, concerts, and installations requiring top-tier audio
Product-related questions and answers:
Q: What type of events is this power pack suited for?A: It’s perfect for large venues like concert halls, festivals, or outdoor events, with 11,600W and 136 dB SPL capability to cover big crowds.
Q: Do I need additional equipment to use this system?A: No, it’s a complete package with speakers, subs, and cables. You’ll only need a mixer or audio source to get started.
Q: How portable is this system?A: Each component is heavy (ETX-35P at 38.2 kg, ETX-18SP at 51.8 kg), so while manageable with handles, transporting all six units may require a team or cart.
Q: Can I use the cardioid feature with the four subs?A: Yes, the four ETX-18SP subs can be configured in cardioid mode via DSP to direct bass forward and reduce stage noise.
Q: Is it easy to set up for someone new to PA systems?A: The FIR-Drive DSP simplifies tuning with presets, but its scale and complexity might require some audio knowledge for optimal use.
Q: Can this be used outdoors?A: Yes, for temporary outdoor events, but it’s not weatherproof, protect it from rain and extreme conditions.
Q: What’s the warranty period?A: Electro-Voice typically offers a 3-year warranty on powered speakers, though confirm with us for exact terms.
Q: Are poles included for mounting the ETX-35P on the subs?A: No, speaker poles (e.g., ASP-58) are not included and must be purchased separately.
Q: How does it handle bass-heavy music like EDM?A: With four 18" subs reaching down to 28 Hz and 7200W of sub power, it excels at delivering deep, impactful bass for EDM or similar genres.
Q: Can I expand this system further?A: Yes, the XLR outputs on both the ETX-35P and ETX-18SP allow for additional speakers or subs to be connected.
