10" + 1" Active Loudspeaker with LCD display and DSP - 900W RMS
ProMaxX 110a is an active speaker equipped with a 10' custom FBT speakers complete with a 1" B&Cs compression driver 900w RMS HF - 90°H x 60°V disperssion - Designed, Engineered and Manufactured in Italy
With a specially developed polypropylene cabinet and stylish full grille aesthetic, the new PROMAXX by FBT represents the next step in the evolution of a portable sound classic.
Equipped with custom FBT speakers complete with B&C’s renowned compression driver technology,PROMAXX combines true made-in-Italy quality and style. At its heart is a purpose-built FBT amplifier module with a switch-mode power supply. For the low frequency section, 700W RMS is driven via a highly efficient Class-D topology, boasting extremely low THD. For HF, meanwhile, 200W RMS is delivered by a Class-H / AB design chosen to ensure the highest definition of audio performance at high frequencies.
Also onboard is a powerful digital signal processing (DSP) platform made available to users of all levels thanks to an intuitive graphical user interface. Located on the rear of the enclosure, the menu-driven system is navigated via a single rotary control with push-to-select functionality.
Users can choose between 6 equalizer presets, each carefully designed by FBT engineers to ensure that every application is catered for (see below). Additionally, 2 preset slots are available for users to form their own designs, using 5 parametric equalizers per slot. Also available is a high-pass filter, a mic/line selector, low, mid and high tone settings and an optional delay of between 0 and 10 metres. Finally, users can exclusively choose between two limiter modes, MAX-SPL or MAX-QUALITY, to best suit their performance,
The PROMAXX feature-set is matched by the enclosure’s versatility, with options for pole-mounting, wall-hanging, suspension or even deployment in an array. The result is the most accessible PROMAXX yet.
PROMAXX offers 6 presets to cater for a broad variety of uses, each crafted by FBT engineers. Employing powerful DSP, the presets ensure reliability while eliminating distortion.ORIGINAL / LIVE The renowned, smooth FBT soundVOCAL A special EQ setting to maximise speech intelligibilityDJ Designed to keep the energy high and your audience dancingTOURING The reliability and the roar of the industry’s most popular touring systemsLOUDNESS The ultimate preset for listening at a medium or low volumeWARM A special setting to emphasise full-bodied, low-mid frequencies.
Key Features
2-way, bi-amplified, bass reflex design cabinet
Biamped: 700W RMS LF, 200W RMS HF, power amplifiers in Class D for LF and in
Class H/AB for HF with switch mode power supplies
Digital signal processor with graphic display
Control Panel features balanced XLR/Jack input, XLR LINK OUT, 2 x Volume, RCA
Stereo input, DSP display with rotative encoder and push
2 x M10 suspension points, 35 mm (1,3/8”) top-hat speaker stand socket, wall bracket mount flange plate
90°H x 60°V constant directivity horn
Front of House or Stage Floor Monitor: with 12°, 40° and 55° monitoring angles
250mm (10") LF woofer with 50mm (2") voice coil, custom made for FBT
25mm (1") throat exit B&C HF magnet compression driver with 34mm (1.4”) voice coil
Frequency response from 58Hz to 20KHz
Sturdy, gas-injected polypropylene molded enclosures, engineered to contain undesired resonance
Extremely light only 10.3kg/22.70lb
Speaker Specifications
Feature
Specification
Configuration
2 Way
Frequency Response
58Hz - 20kHz (-6dB)
Low Frequency Woofer
10"
High Frequency Driver
1"
Maximum SPL (Continuous/Peak)
124/131dB
Dispersion (H x V)
90° x 60°
Input Impedance
22kOhm
Input Connector
XLR/Jack Combo socket with XLR link out, RCA stereo input
Net Dimension (WxHxD)
320 x 550 x 275mm
Net Weight
10.3kg
Transport Dimension (WxHxD)
400 x 630 x 360mm
Transport Weight
12.8kg
AC Power Requirements
640VA
Built-in Amplifier (LF/HF)
900W (700W LF + 200W HF)
