Optimal Audio Zone 4P - 4-Zone Powered Audio Controller with DSP & WebApp
The Optimal Audio Zone 4P is a powerful and intuitive 4-zone powered audio controller, designed for straightforward and cost-effective installation in small to medium-sized applications. It integrates amplification and comprehensive audio signal management with DSP, allowing users to independently allocate and control sources across four configurable zones. Featuring an intuitive WebApp interface and seamless compatibility with other Optimal Audio products, the Zone 4P provides superb sound quality and easy access to everyday controls.
Key Features
-
4 Configurable Zones: Independently allocate and control audio sources across up to four distinct areas.
-
Integrated Amplification: Includes 4 channels of integrated amplification, eliminating the need for separate amplifiers for most small to medium applications.
-
Comprehensive Inputs: Features 2 mic inputs (with 48V phantom power), 4 stereo line inputs (with SPDIF option on input 1), and 2 HDMI inputs for TV and video sound.
-
WebApp Interface: Provides easy system configuration and everyday control via an intuitive WebApp.
-
Flexible Signal Routing: Allows for full flexibility in routing audio signals to different zones.
-
DSP with Loudspeaker Presets: Includes a full suite of audio controls and DSP for precise sound management.
-
Programmable Presets & Timed Events: Supports fully programmable presets and timed events for automated control.
-
Microphone Input Processing: Features fixed hi-pass filter, sweepable mid-band EQ, and HF shelf for mic inputs.
-
ZonePad Compatibility: Designed to work seamlessly with ZonePad series for simple and intuitive control.
Technical Specifications
-
Type: 4 zone audio processor with DSP, amplification, and loudspeaker presets.
-
Mic Inputs: 2 (with 48V phantom power, +12dB to +55dB gain).
-
Mic Input Processing: Fixed hi-pass filter @160Hz; sweepable mid-band 200Hz-5kHz, +/-12dB; HF shelf @12kHz.
-
Line Inputs: 4 stereo (with +26dB gain trim. SPDIF option on input 1).
-
HDMI Inputs: 2.
-
Line Outputs: 4.
-
ZonePad Sockets: 4.
-
Amplifier Channels: 4.
-
Amplifier Power: 100W at 4Ω or 8Ω.
-
Paging Inputs (CAT 5): 2.
-
LAN Ethernet: 100Mbps.
-
Alarm Override: Yes.
-
Dimensions (W x H x D): 480mm x 88mm x 400mm (18.90” x 3.46” x 15.75”).
-
Weight: 9.75kg (21.5lbs).
Suitable For
- Bars.
- Back of house areas.
- Lobbies.
- Restaurants.
- Kitchens.
- Shop floors.
- Small to medium audio installations requiring multi-zone control and integrated amplification.
- Installations requiring TV/video sound integration.
What's in the box
- Optimal Audio Zone 4P 4-Zone Powered Audio Controller.
- (Power cable and user manual
