The Obsession HP is a compact yet powerful LED effect light designed to create eye-popping, animated gobo light shows. Fitted with a bright 100W LED, this fixture projects multi-coloured, rotating gobos, making it ideal for clubs, mobile DJs, and event productions that require complex and dynamic lighting looks. Its design power and flexibility are significantly enhanced by inter-changeable gobos, allowing for limitless creative customization.
-
Powerful 100W LED Engine: Fitted with a single 100W cool white LED (with a 50,000-hour life expectancy) that projects bright, multi-coloured, and rotating gobos, ensuring vivid mid-air effects.
-
Complex Effects Generation: Features a rotating gobo wheel (with 7 metal gobos) plus an onboard mirror dish to easily generate complex, animated lighting looks with continuous scroll and indexing capabilities.
-
Interchangeable Gobos: Increases design flexibility by allowing users to change the gobos, which includes 10 popular holiday gobos right out of the box.
-
Dedicated Colour and Gobo Control: Separate colour and gobo wheels allow for intricate and creative programming, ensuring greater control over the final effect. The colour wheel offers 6 colours + white, split colours, and continuous scroll at variable speeds.
-
Synchronized Shows and Power Linking: Generate a synchronized show in Master/Slave mode with up to 2 units. Save time running cables by power linking multiple units (3 units @ 120 V; 6 units @ 230 V).
-
Flexible Control: Controllable via DMX (2 or 8 channels) and compatible with the optional IRC-6 infrared remote for flexible, non-DMX control over all features.
-
Compact and Portable: Features a compact size and lightweight design (4.7 kg), making it easy to transport. It fits best in the CHS-40 VIP Gear Bag.
-
Light Source: 1 LED (cool white) 100 W (4 A)
-
Life Expectancy: 50,000 hours
-
DMX Channels: 2 or 8 selectable
-
DMX Connectors: 3-pin XLR
-
Colours: 6 + white, split colours, continuous scroll
-
Gobos: 7 metal, rotating, indexing, interchangeable, continuous scroll
-
Gobo Size: 18 mm outside, 12 mm image, 5 mm max thickness
-
Strobe Rate: 0 to 20 Hz
-
PWM Frequency: 4 KHz
-
Coverage Angle: 116°
-
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
-
Power and Current (Max): 176 W, 2.2 A @ 120 V, 60 Hz | 171 W, 1.3 A @ 230 V, 50 Hz
-
Size (LxWxH): 380 x 233 x 305 mm (14.96 x 8.26 x 12 in)
-
Weight: 4.7 kg (10.2 lb)
-
Approvals: CE
-
Optional Controller: IRC-6
