The VX600 is capable of receiving a variety of video signals and processing high-resolution images. In addition the device features stepless output scaling low latency pixel-level brightness and chroma calibration and more to present you with an excellent image display experience.
What's more the VX600 can work with NovaStar's supreme software NovaLCT and V-Can to greatly facilitate your infield operations and control such as screen configuration Ethernet port backup settings layer management preset management and firmware update.
Thanks to its powerful video processing and sending capabilities and other outstanding features the VX600 can be widely used in applications such as medium and high-end rental stage control systems and fine-pitch LED screens.
Specifications
Loading Capacity:
• 3.9 million pixels
Maximum pixel width & height:
Width up to 10240 pixels Height up to 8192 pixels
Layers:
3x 2K×1K
Inputs:
_x005F
• 2x HDMI1.3
_x005F
• 1x DVI
_x005F
• 1x 3G-SDI
_x005F
• 1x OPT1
_x005F
Outputs:
_x005F
• 6x Ethernet Ports for LED Screen connection
_x005F
• 1x HDMI (Monitoring or Output)
_x005F
• 1x HDMI1.3 LOOP
_x005F
• 1x DVI LOOP
_x005F
• 1x 3G-SDI LOOP
_x005F
• 2x OPTICAL for LED Screen connection
_x005F
_x005F
Control:
_x005F
• GENLOCK (IN & LOOP):Yes
_x005F
• 1x Ethernet Port
_x005F
• 1x USB-A
_x005F
• 1x USB-B
_x005F
• Low Latency: Yes
_x005F
• Input Source Backup: Yes
_x005F
• Bypass Mode: Yes
_x005F
• Fiber Converter Mode: Yes
_x005F
Electrical & Environmental:
Power connector 100–240V~ 1.5A 50/60Hz Rated power consumption 28 W Temperature –10°C to +60°C Humidity 20% RH to 90% RH non-condensing
Dimensions & Weight:
Dimensions 483.6 mm × 351.2 mm × 50.1 mm Weight 4 kg
Included accessories:
1x Power cord 1x HDMI to DVI cable 1x USB cable1x Ethernet cable 1x HDMI cable 1x Quick Start Guide 1x Certificate of Approval 1x Customer Letter 1x Safety Manual
