Mercury Economy Cat5e U/UTP Network Cable 305m Grey

Solid conductor twisted pair data cable supplied in dispensing box and marked at 1 metre intervals. Suitable for high speed data transmission such as Gigabit Ethernet applications.

Passes Cat5e fluke test 100m at 100MHz
Solid copper clad aluminium conductor
Supplied in an easy-pull dispensing box

Conductor Solid CCA
Strands 8 x 1/0.51mmØ ±2%
CSA 8 x 0.204mm²
Cable : diameter 5mmØ
Insulation HDPE 0.19mm thickness
Sheath PVC 0.5mm thickness
Impedance 100 Ohms (±15)
DC resistance @ 20°C <35 Ohms/100mt
Return loss >20dB @ 100m
NEXT >40dB @ 100m
PSNEXT >38dB @ 100m
Cable colour Grey
Length 305m
Weight 6kg

Product form

Mercury Economy Cat5e U/UTP Network Cable 305m Grey

Free pickup in our shop(s)

£69.00

  • Available
  • Fast tracked delivery
  • Service excellence guaranteed
    iFrame
    ×
    • Don't want to order online? Call us on 01635 780002

    SKU: 808.021UK
    Barcode: 5015972172254

    Trustpilot

    Solid conductor twisted pair data cable supplied in dispensing box and marked at 1 metre intervals. Suitable for high speed data transmission such as Gigabit Ethernet applications.

    Passes Cat5e fluke test 100m at 100MHz
    Solid copper clad aluminium conductor
    Supplied in an easy-pull dispensing box

    Conductor Solid CCA
    Strands 8 x 1/0.51mmØ ±2%
    CSA 8 x 0.204mm²
    Cable : diameter 5mmØ
    Insulation HDPE 0.19mm thickness
    Sheath PVC 0.5mm thickness
    Impedance 100 Ohms (±15)
    DC resistance @ 20°C <35 Ohms/100mt
    Return loss >20dB @ 100m
    NEXT >40dB @ 100m
    PSNEXT >38dB @ 100m
    Cable colour Grey
    Length 305m
    Weight 6kg
