Martin Audio CDD-LIVE 12 | High-Performance 12-Inch Active PA Speaker
Touring-grade power, point-source precision. The Martin Audio CDD-LIVE 12 is a self-powered, two-way system designed for professional applications that demand high SPL and exceptional fidelity. Whether used for portable live sound, theatre reinforcement, or premium fixed installations, the CDD-LIVE 12 delivers a peak output of 128dB with absolute clarity. Its 12-inch Coaxial Differential Dispersion (CDD) driver provides a consistent, wide coverage pattern that outperforms traditional speakers, ensuring every member of the audience hears the full frequency spectrum with perfect detail.
Why Choose the CDD-LIVE 12?
-
Elite Coaxial Technology: The CDD driver achieves a "point source" summation of low and high frequencies, eliminating off-axis tonal shifts and providing a natural, transparent sound.
-
Massive 2500W Peak Power: Incorporates a dedicated two-channel Class D amplifier delivering 2000W to the LF and 500W to the HF sections.
-
Differential Dispersion Advantage: Provides a wide 110-degree horizontal coverage close-up, narrowing to 60 degrees at a distance for perfectly consistent room coverage.
-
Dante Digital Integration: Onboard Dante networking allows for seamless digital audio distribution and system control over a single network cable.
-
Multi-Angle Versatility: The tour-grade plywood enclosure is designed for use as a main PA, a side-fill, or a high-performance stage monitor with a user-rotatable driver for horizontal or vertical placement.
Advanced System Control and Architecture
Total Remote Management Using Martin Audio's VU-NET software, engineers can remotely manage every aspect of the CDD-LIVE 12. From parametric EQ and delay to muting and gain control, the system can be tuned via a PC or tablet over a standard Ethernet network. For smaller events, high-quality "plug-and-play" presets are accessible directly on the rear panel.
Robust Professional Engineering The CDD-LIVE 12 is built to endure the most demanding environments. The enclosure is constructed from extensively braced multi-laminate plywood and coated in a hard-wearing textured polyurea finish. A screw-free protective grille allows for quick access to the driver, while 15 x M8 mounting points and a built-in top-hat offer endless rigging possibilities.
Universal Global Power Equipped with an auto-ranging switch-mode power supply, the CDD-LIVE 12 works globally on any voltage from 100V to 240V. The use of Power Factor Correction (PFC) and Neutrik Powercon True1 connectors ensures maximum electrical efficiency and a secure, professional connection at all times.
Technical Specifications
-
Type: High-performance, Coaxial Differential Dispersion active two-way system
-
Driver: 12-inch LF (3-inch voice coil) / 1-inch exit HF Coaxial Driver
-
Frequency Response: 62 Hz to 20 kHz (plus/minus 3dB)
-
Max SPL: 122dB continuous / 128dB peak
-
Dispersion: 110-60 degrees Horizontal, 60 degrees Vertical (User-rotatable)
-
Amplifier: 2500W Total Peak (Class D)
-
Connectivity: XLR Input/Link, Dante Ethercon (RJ45), Powercon True1
-
DSP: Onboard PEQ, Delay, and Preset selection via VU-NET
-
Cabinet: Braced multi-laminate plywood with polyurea coating
-
Weight: 28.0 kg
Frequently Asked Questions
Is this speaker suitable for touring? Absolutely. The CDD-LIVE 12 is designed as a touring-standard system with a rugged polyurea finish and professional Dante networking. Its high output and compact size make it an ideal choice for regional touring and high-end rental companies.
Can I use it without a computer? Yes. While the VU-NET software offers deep control, the rear panel features "plug-and-play" presets that allow you to optimize the speaker for pole-mount, monitor, or sub-satellite use instantly.
What are the mounting options? The speaker is incredibly flexible, featuring a top-hat for pole mounting and 15 x M8 inserts. These can be used with Martin Audio's wall, yoke, or universal brackets, allowing the speaker to be rigged at almost any angle.
What is In The Box?
