RG-59 style coaxial cable designed for analogue or HD-SDI video signals up to 12Gbps commonly used for high definition video signals in the event production sector. The cable is constructed from a single oxygen-free copper core protected by both aluminium polyester foil and a tinned oxygen-free copper woven braid designed to reject interference. The cable is finished with a low memory super flexible outer PVC jacket for the ultimate flexibility. Sold per metre (Please specify your requirements in the notes section when ordering eg 20m in 1m cuts 50m in 10m cuts etc) 75Ω impedance Solid oxygen free copper core Shield 1: Aluminium foil 125% coverage Shield 2: Braided screen 95% coverage Super flexible PVC outer jacket Conductor: 1 x 0.23mm² (24AWG) Dielectric: 1.2mm Polyethylene foam Outer diameter: 6mm Operating temperature range: -20 to +80°C
