The Vortex 150 continues to redefine dynamic lighting with its classic moonflower effect and barrel mirrored scanner. Powered by a robust 150W white LED engine it delivers razor-sharp 3-degree beams that cut through the air with precision. Featuring 11 vibrant Colour/GOBO combinations GOBO shake effects mesmerizing strobe effects and 6 built-in light shows the Vortex 150 is designed to captivate audiences and help bring a party to life.
Take control with multiple operation modes including DMX Remote Device Management (RDM) sound activation or show mode. Adjust settings effortlessly using the intuitive 4-button control menu and digital display. The barrel mirror ensures rapid fluid movements with a range of 180° on the X-axis and a full 360° on the Y-axis. Fine-tune the beams and GOBO patterns using the manual focusing knob for ultimate precision.
The fixture is equipped with 5-pin DMX In/Out connections an IP65 locking power input and a safety loop for secure mounting. Compact and lightweight the Vortex 150 is ideal for tight spaces low ceilings and high-energy venues such as bars lounges roller rinks and fun centres.
Light Source:
150W White LED (30000 Hrs.)
Barrel Mirror:
Barrel Movement: X-Axis = 180° Y-Axis 360° Beam Angle: Multiple Beams 3° each Beam Focusing Knob
Colours/GOBOs:
11 Colour / Gobo combinations (2 Beam Reducers) Colour/Gobo Shake
Control:
DMX512 RDM Sound and Show Mode 0.5-33Hz Strobe Rate User selectable LED Refresh Rate 6 Built-In Light Shows DMX Modes: 2 DMX Control Modes (10 & 12 Channels) 4-Button Digital Display Screen
Connections:
5-pin DMX In/Out IP65 Locking power input Safety eye to attach a safety cable
Electrical:
Power: 100-230VAC 50/60Hz Power Consumption: 175W @ 230V
Size / Weight:
Dimensions (LxWxH): 339x235.6x334.4mm Weight: 5.1 kg
Approvals:
CE and cETLus (Pending) IP20
Included:
Adjustable Angle Hanging Bracket Power Cable
Specifications are subject to change without notice.
